X-ray Baggage Scanner: SF6040 PRO

Description

◆ Display: High-resolution 19-inch color LCD display;
◆ Color quality: 24-Bit
◆ X-ray sensor—L type photodiode array detector (energy), 24-bit depth
◆ Single energy: L-shaped Array detector
◆ Beam Direction: Upward;
◆ Tube Current: 0.4-1.25MA;
◆ Anode voltage: 140-160KV;
◆ X-ray divergence angle: 80 °;
◆ Cooling: Sealed oil bath with forced air;
◆ Sealed oil bath with forced air/100%;
◆ Warranty Two years
◆ Have CE , ISO, FCC, ROSH certification

Category:
  • Share:
Description



The Bahria Security SF6040 PRO is another model of X-ray baggage scanner that is widely used for security screening purposes in airports, train stations, government buildings, and other high-security facilities. This scanner is designed to provide efficient and reliable screening of baggage and various items.The SF6550C boasts a sturdy construction with a spacious scanning tunnel, allowing for the screening of a wide range of baggage sizes and shapes. It employs advanced X-ray imaging technology to produce high-resolution images of the baggage contents. These images are displayed on a color monitor for analysis by trained operators.

Features and Benefits

One of the notable features of the UNIQSCAN SF6550C is its fast scanning speed, enabling rapid and streamlined screening operations, particularly in high-volume environments. The user-friendly interface and intuitive controls make it easy for operators to navigate through the X-ray images and identify potential threats with accuracy.
Similar to other modern X-ray baggage scanners, the SF6550C incorporates advanced capabilities such as automatic threat detection and image enhancement. These technologies enhance the accuracy and efficiency of the screening process, enabling operators to quickly identify potential threats and ensure the safety of the screening area.

The UNIQSCAN SF6550C is designed to meet international safety and security standards. It incorporates safety features such as radiation shielding and interlocks to safeguard the operators and passengers. The manufacturing process of the scanner undergoes rigorous testing and quality control measures to ensure its compliance with stringent security requirements.
UNIQSCAN X-ray baggage scanners like the SF6550C have become indispensable tools for enhancing security across various settings. By utilizing non-intrusive scanning technology, they enable the detection of dangerous items, such as weapons or explosives, without the need for physical searches. Consequently, they play a vital role in maintaining the safety and security of transportation hubs and other high-risk locations.
Please note that specific features and benefits of the SF6550C may vary depending on the manufacturer and model specifications. For accurate and up-to-date information about the SF6550 or any specific model, it is advisable to consult the official documentation or contact the UNIQSCAN directly.

X-ray Baggage Scanner: SF6550CX-ray Baggage Scanner: SF6550C

IMAGE PERFORMANCE SYSTEM

  • Display: High-resolution 19-inch color LCD display;
  • Display Resolution: 1280*1024;24 bit/pixel Color;
  • Color management architectures: Different color, different matter;
  • High penetration display: Increase the contrast of bright area in image to make the area that is easy to penetrate appear more clearly;
  • Low penetration display: Increase the contrast of dark area in image to make the area that is difficult to penetrate appear more clearly.
  • Automatic image enhance: enhance and optimize small images up to display resolution;
  • Multi-energy image, showing in different colors (organic, non organic etc.) with the ability to highlight or exclude organic materials.
  • Edge enhancement: The edge of image is more clear;
  • Contrast Sensitivity: 24 Visible Levels, 4096 Gray Level;
  • Zoom in up to 64x/zoom out;
  • Display the previous twenty images and process any one of them; Restore image to initial status;
  • Brighter/darker: Make image more bright /make image darker;
  • Replay: Playback all images on the screen at current, be able to do the next steps;
  • Image resolution enhance technology;
  • Full automatic diagnostics;
  • Remote access to image storage via Ethernet;
  • Saving images up to 100,000 files;
  • Display of date, time, and baggage counter.

Smart software: Automatic control of the generator, X-ray detector, electronic control system (controller), and peripherals.

X-ray safety detection equipment can display color and black and white images, with simple and efficient operation, with reasonable human design. We provide a fully intelligent and secure inspection system for our customers. Automatic detection of explosives, narcotic substances, and high-density materials, and marking of dangerous areas on the image with alarm trigger for a fast operator response. We provide an intelligent and secure inspection system for our customers.
